1.4460 Duplex Stainless Steel Round Bar 50mm OD EN10204 3.1

MOQ:	100 kg
Preis:	3.5-5.85 USD/KG
Standardverpackung:	Seefahrtfähiges Paket
Lieferfrist:	15 Arbeitstage
Zahlungsmethode:	L/c, t/t
Lieferkapazität:	500 Tonnen/Monat

Einzelheiten Informationen

Beschreibung des Produkts

Einzelheiten

Herkunftsort

China

Markenname

TSING SHAN

Zertifizierung

ASTM,AISI,JIS,SUS,DIN,EN

Modellnummer

329 (UNS S32900/1.4460)

Grad:

329 (UNS S32900/1.4460)

Material:

Edelstahl

- Die Bar.

Außendurchmesser:

6-630mm

Länge:

Besonderheit:

Hohe Stärke

Materielle Kategorie:

AUSTENITedelstahl

Gegeben:

Haltbarkeit:

Lang anhaltende

Unterschiedliche Form:

Runde, flache, quadratische, sechsseckige, Ect

Ursprung:

Jiangsu (Kontinent China)

Verarbeitungsmethoden:

Maschinenbearbeitung, Kaltbearbeitung usw.

Lieferfrist:

UHRKETTE CFR CIF CNF

Prozessmethode:

kaltbezogen/kaltgewalzt/warm gewalzt

Probenreihenfolge:

Akzeptiert

Hervorheben:

1.4460 duplex stainless steel round bar

EN 10088-3 certified stainless steel bar

50mm OD duplex steel round bar

Beschreibung des Produkts

1.4460 (EN 10088-3) Duplex Stainless Steel Round Bar OD 50mm With Certificate Type 3.1 EN10204.

The Stainless Steel Type 329 is duplex steel being a combination of austenitic and ferritic types. It can resist pitting as well as corrosion cracking under stress. This type of steel is better to use in forged valve pumps and their components.

Type 329 is also frequently used for centrifugal machines. This type of steel forges better at temperatures around 1250/1050C or 2280/1900F. The parts need to be air-cooled once they are forged. Duplex steel of such grade is very difficult to weld, and hence its machinability is very low.

Common Names: The other names of stainless steel 329 are AISI 329, and UNS S32900.

Executive Standards:

ASTM A240
ASME SA240
ASTM A268
ASME SA268
ASTM A789
ASME SA789
ASTM A790
ASME SA790
ASTM A511
ASME SA511
DIN 1.4460

Chemical Properties:

Elements	Content
Iron	63%
Chromium	28%
Nickel	4.5%
Manganese	2%
Molybdenum	1.5%
Silicon	1%
Carbon	0.10%
Phosphorous	0.040%
Sulfur	0.030%

Mechanical Properties:

Properties	Metric
Ultimate tensile strength	725 MPa (105000 psi)
Tensile strength, yield (@0.2%)	550 MPa (79800 psi)
Elastic modulus	190 to 210 GPa (27557 to 30458 Ksi)
Poisson’s ratio	0.27 – 0.30
Elongation (50 mm)	25%
Hardness, Brinell (Knoop) (RB) (RC) (Vickers)	230 (253) (96) (20) (242)

Physical Properties: The most notable physical property of SS Type 329 is its density which is 7.80 g/cm3 (0.282 lb/in3

Key Features:

The thermal expansion coefficient (TEC) at 20C to 815C (68F to 1500F) is 14.4µm/mC (8 µin/inF).
Slightly lower alloy content as compared to Grade 2205.
Parts and components must be solutions annealed at around 1020C to 1100C (1870F to 2010F) and then must be quenched in water.

Product Forms Available:

Plates
Pipes
Round Bar
Tube
Flanges
Wire
Fittings

Applications:

Off-shore technology.
Paper industry.
Chemical tanks.
Heat exchangers.
Refineries.
Flanges, fittings, and pipes for the oil and gas industries.
Compressor parts.
Marine shafts for pressure vessel parts.
Desalination plants at seawater.

1.4460 Duplex Stainless Steel Round Bar 50mm OD EN10204 3.1 0

1.4460 Duplex Stainless Steel Round Bar 50mm OD EN10204 3.1 2

FAQ:

Q1: How many countries you already exported?

A1: Exported to more than 50 countries mainly from , UK,Vietnam, Egypt, Turkey, Saudi Arabia,Dubai etc.

Q2: How long will it take to execute my order?

A2: Our normal time to execute the order is 7-20 working days. We will let you know the estimated lead time after payment ASAP.

Q3 Can I have a sample for testing?

A3: Free samples, you just need to pay the freight.

Q4 Do you have inspection for the products before packing?

A4: 100% self-inspection for the products, we put the quality as our first priority.

Q5 Can I have a visit to your factory before the order?

A5: Sure, welcome to visit our factory.
